TKT TRUCK REFRIGERATION Units BRIEF INTRODUCTION

Brief Introduction of TKT Truck Refrigeration Units:
TKT products already cover the entire range of transport refrigeration units, TKT offers a full range of truck refrigeration unit solutions for your refrigerated trucks, cold chain transport, insulated bodies, etc.
Considering the different demands of customers for Truck refrigeration systems, Truck refrigeration units generally include two types, one for transporting fresh cargo and the other (freezer unit) for transporting frozen cargo on the road, as for truck freezer unit, is mainly divided into small truck refrigeration unit, mid truck refrigeration unit and large truck refrigeration unit. Depending on refrigeration system driven type, it can be classified as: Vehicle Engine Direct Driven Units, Engine Direct Driven unit with AC220V/380V Electric standby unit and Diesel engine driven units respectively.
This page only introduces the Vehicle Engine Direct Driven Units.

Specification Table:
The Critical components TKT Refrigeration Units system uses are imported from Famous World Top Brand with High Quality, and a stylish design that fits any Truck model.
Tips: Depending on the type of vehicle, ambient temperature, transported cargo and required cooling capacity, you can choose the most suitable product with the help of our sales team.

Model		TKT-200C	TKT-300C	TKT-200F	TKT-400F	TKT-600F	TKT-800F	TKT-900F

Driven Type		Engine Driven
Structure		Front Mounted
Compressor		JAP SD5S14 (138cc)	JAP SD5S14 (138cc)	JAP SD5S14 (138cc)	JAP SD5S14 (138cc)	Valeo TM16(155cc)	Valeo TM 21	Valeo TM21
Voltage		DC12v / 24V
Container Volume		3CBM/2.2 Meters	6CBM/3.2Meters	4CBM/2.2 Meters	7CBM/3.2 Meters	16CBM/4.2 Meters	20CBM/5.2 Meters	25CBM/6.2 Meters
Container Volume		Body (-5℃ )	Body(-5℃ )	Body (-20℃ )	Body (-20℃ )	Body (-20℃ )	Body (-20℃ )	Body(-20℃ )
Refrigerant		HFC-134A, 0.9-1.0Kg	HFC-R404A,1.2-1.4kg	HFC-R404A, 1.2-1.4Kg	HFC-R404A, 1.5-1.6Kg	HFC-R404A, 2.2-2.3Kg	HFC-R404A, 2.3-2.4kg	HFC-R404A 2.4-2.6kg
Controller		Digital, In Cab
Cooling Capacity		-5℃-1440 W/4900 BTU	-5℃-2470W/ 8424 BTU		-18℃-1804 W/6150 BTU		-20℃-3680W/12550 BTU
Cooling Capacity		0℃-1870 W /6370 BTU	0℃-2990W/10200BTU		0℃-3666 W /12500 BTU		0℃-7480W / 25500 BTU
Condenser	Coil	Copper Tube & Aluminum Fin
	Fan No.	1 Fan, DIA 280MM			2 Fans, DIA 250MM	2 Fans, DIA 300MM	3 Fans, DIA 300MM	3 Fans, DIA 300MM
	Dimension	789450212 mm			1050470310 mm	1080510375 mm	1280504.6375mm	1280504.6375 mm
Evaporator	Coil	Copper Tube & Aluminum Fin
	Blower No.	1 Blower, DIA 230MM	1 Blowers(Turbo)	1 Blowers(Turbo)	2 Blowers, DIA 230MM	2 Blowers (Turbo)	3 Blowers, DIA 230MM	4 Blowers, DIA 230MM
	Air Flow	610m3/h	955m3/h	955m3/h	1120m3/h	1870m3/h	1910m3/h	2560m3/h
	Dimension	706595190mm	1010593185mm	1010593185mm	1006590188mm	1260593185mm	1389613184 mm	1556611185 mm

Truck Refrigeration Units Design Advantage:

A variety of models to choose & Easy to Operate

This series includes fresh and frozen functions, and the right model can recommend for you according to your different requirements of the cargo type, ambient temperature and the length of the cargo truck;
Besides, Our truck Refrigeration System has multi-functional controller with microprocessor control system, and temperature control panel in the cab for the driver to better control the temperature of the Truck's Container.

High quality Critical components and the best raw materials

The Critical components TKT Refrigeration system uses are imported from Famous World Top Brand with High Quality，such as Danfoss, Sanden, Valeo, etc.;
For Condenser and Evaporator coils, TKT uses all Copper Tubes and Aluminum Fin, corrosion-resistant, so the service life can be up to more than ten years, to improve the life time of the product.

Stylish and intimate design, Easy to Install

This series are all Front-mounted design, easy to install; The condenser is streamlined and compatible with any truck model, and Slimline design of Evaporator for maximum cargo space.

Green & Environment-friendly

Uses ozone-friendly refrigerant R134A, R404A.

Really powerful Cooling Capacity, Higher efficiency and more stable working.

TKT refrigeration system uses condensers and evaporators made of the best materials (Copper Tubes and Aluminum Fin) to bring you super cooling effect and maximum Air flow capability, Reliable performance to stand against Hot & Dusty climatic conditions.

Safe Voltage Level

Low current, High-Low voltage protection and more secure system.

Guarantee the integrity of the cargo during loading and unloading

For the stand by unit, capable of the pre-cooling of the container in advance. Besides, ensures normal operation of the refrigeration unit even when the truck is turned off.

Certificated by Various High Standard in US and Europe;

CE, RHS etc. Certificate.

Certification of TKT Truck Refrigeration Units:

Test Video of TKT Truck Refrigeration Units:

All Product:

If you are interested in working with TKT, please feel free to contact us.
